RESI-UI-2P2SW2L-RD

RESI-UI-2P2SW2L-RD

New product

Signal and control module compatible to DIN ISO 16484 and VDI 3814 with 2 10kOhm potentiometers and 2 switches with three positions LEFT-CENTER-RIGHT and 2 24Vdc LEDs in RED

More details

Add to wishlist

Data sheet

Protocol SIGNAL
Interface #1 2xPOTI+2xSWITCH+2xLED
Interface #2 POWER SUPPLY:4x0..60Vdc
LxWxH 72x110x62mm
Weight 175g
Power Supply 2A@250Vac,5A@120Vac,5A@28Vdc+24Vdc
Category VDI3814-DIN ISO 16484

More info

Manual control and monitor module with 2 potentiometers (10kOhm, max. 0.5W), 2 switches and 2 LEDs (24Vdc, max. 20mA) in RED. Each switch offers three positions: UP-CENTER-DOWN. A 18 pin removable terminal block for wiring of all elements. Contact rating of the switches with resistive load: max. 5A@28Vdc. 4 internally bridged 2 pin terminal blocks to distribute the power supply (max. 60Vdc, max. 4A). Module suitable to build up a DIN ISO 16484 and VDI 3814 compatible manual operator interface, Weight: 175g, Dimension (LxWxH): 72x110x62mm, Snap able onto a EN50022 DIN rail or wall mounting.

help and more information about this product under RESI-WIKI

Download

RESI-M-UI-BR-MODULES-D10.pdf

Manual for our RESI-UI-xxx and RESI-BR-xxx products in German

Download (3.95M)

RESI-M-UI-BR-MODULES-E10.pdf

Manual for our RESI-UI-xxx and RESI-BR-xxx products in English

Download (4.12M)

RESI-FA4-UI-MODULES-D10.pdf

Flyer for our RESI-UI-xxx products in German

Download (699.08k)

RESI-FA4-UI-MODULES-E10.pdf

Flyer for our RESI-UI-xxx products in English

Download (696.3k)

RESI-DS-UI-2P2SW2L-xx-D10.pdf

Data sheet for our RESI-UI-2P2SW2L-xxx products in German

Download (209.01k)

RESI-DS-UI-2P2SW2L-xx-E10.pdf

Data sheet for our RESI-UI-2P2SW2L-xxx products in English

Download (206.63k)

RESI-PA-UI-2P2SW2L-RD-DE10.pdf

Product attachment for our RESI-UI-2P2SW2L-RD product in German/English

Download (301.07k)
