RESI-UI-4L-RD
RESI-UI-4L-RD
New product
Signal module compatible to DIN ISO 16484 and VDI 3814 with 4 24Vdc LEDs in RED
| Interface #1 | 4xLED |
| Interface #2 | POWER SUPPLY:4x0..60Vdc |
| Protocol | SIGNAL |
More info
Signal module with 4 build-in LEDs (24Vdc, max. 20mA) in RED to show the state or errors of machines. Each LED is wired via a removable 2 pin terminal block. 4 internally bridged 2 pin terminal blocks to distribute the power supply (max. 60Vdc, max. 4A). Module suitable to build up a DIN ISO 16484 and VDI 3814 compatible manual operator interface, Weight: 150g, Dimension (LxWxH): 72x110x62mm, Snap able onto a EN50022 DIN rail or wall mounting.
help and more information about this product under RESI-WIKI
Download
RESI-PA-UI-4L-RD-DE10.pdf
Product attachment for our RESI-UI-4L-RD product in German/English
Download (220.39k)RESI-M-UI-BR-MODULES-D10.pdf
Manual for our RESI-UI-xxx and RESI-BR-xxx products in German
Download (3.95M)RESI-M-UI-BR-MODULES-E10.pdf
Manual for our RESI-UI-xxx and RESI-BR-xxx products in English
Download (4.12M)
