Signal module compatible to DIN ISO 16484 and VDI 3814 with 4 24Vdc LEDs in WHITE
This product is no longer in stock
Availability date: 0000-00-00
|Interface #2||POWER SUPPLY:4x0..60Vdc|
Signal module with 4 build-in LEDs (24Vdc, max. 20mA) in WHITE to show the state or errors of machines. Each LED is wired via a removable 2 pin terminal block. 4 internally bridged 2 pin terminal blocks to distribute the power supply (max. 60Vdc, max. 4A). Module suitable to build up a DIN ISO 16484 and VDI 3814 compatible manual operator interface, Weight: 150g, Dimension (LxWxH): 72x110x62mm, Snap able onto a EN50022 DIN rail or wall mounting.
help and more information about this product under RESI-WIKI
Manual for our RESI-UI-xxx and RESI-BR-xxx products in GermanDownload (3.95M)
Manual for our RESI-UI-xxx and RESI-BR-xxx products in EnglishDownload (4.12M)
